07 — Governance Tour — Platform vs Data RBAC¶

Time : 5 min · Persona : alice (admin) · Path : A or B

AKKO separates two flavours of RBAC :

Platform Access — which surfaces a role can see (sidebar pages, action buttons, admin panels).
Data Access — which rows and columns a role can read or write inside the catalogs.

They are managed independently and audited side by side.

Pre-requisites

You are signed in as alice.
You completed chapter 03.

Step 1 — Open Platform Access¶

Click Governance in the sidebar, then the Platform Access tab.

You see a matrix : 5 roles × layer chips.

Role	Chips visible
`akko-admin`	every layer
`akko-engineer`	Compute, Lab, Catalog, AI
`akko-analyst`	BI, AI
`akko-viewer`	Home dashboards only
`akko-steward`	Catalog, NORA, Audit

Expected result : the matrix renders, every cell shows ✓ or ✗.

Platform Access matrix

Step 2 — Edit a chip (don't save)¶

Click any chip to toggle it (for example, grant carol the Logs layer).

The cell shows a yellow "pending" border. The Save button at the top right activates.

Don't save — click Discard for this tour. We'll keep the demo state clean.

Why client-side preview. You see the new RBAC posture before committing. The backend only validates and persists on Save, never on toggle.

Step 3 — Open Data Access¶

Switch to the Data Access tab inside the Governance page.

You see a list of catalogs, each with :

Scope — engineering / analyst / viewer / steward / custom.
Row filters — for example region = 'EU' for the analyst scope.
Column masks — for example email → md5(email) for the viewer scope.
PII tags — which columns are flagged by NORA.

Expected result : the catalog list renders with health pills and row/column counts.

Data Access matrix

Step 4 — Inspect carol's scope¶

Click the analyst scope link next to the demo_postgres catalog.

You see :

Field	Value
Row filter	`region = 'EU'`
Column mask	`email → md5(email)`
Tables denied	`internal_audit`, `risk_models`
Aggregation rules	`MIN_GROUP_SIZE = 10` (k-anonymity)

Layer in motion. This scope is enforced server-side by the policy engine. Carol cannot bypass it from ADEN, SQL Lab, BI, or the API.

Step 5 — Live test — switch persona to dave¶

Sign out.
Sign in as dave / dave123.
Try to open the catalog tree via DEMO_HOST/#catalogs.

Expected result : the page shows the AKKO RBAC "tip" banner :

"This area is not available for your role (akko-viewer). Ask your administrator."

A button at the bottom-right says "Request access" — it raises a ticket in the audit log.

Dave RBAC denied

Step 6 — Audit the access¶

Sign back in as alice. Open Logs → filter event=access_denied user=dave.

You see the access-deny event with timestamp, request path, persona, and the RBAC rule that blocked it.

Expected result : at least one entry corresponds to dave's attempted access from the previous step.

Audit-first design. Every denial is logged, every grant is logged, every catalog change is logged. The audit trail is append-only and signed.

How it ties together¶

Identity provider  →  realm role
                          │
                          ▼
              Platform Access matrix  →  sidebar + UI
                          │
                          ▼
              Data Access scope       →  SQL WHERE / column mask
                          │
                          ▼
                  Audit trail (signed)

Layer-first principle. The Platform RBAC matrix maps roles to layers, not to vendor product names. When you swap the BI engine, the matrix doesn't change — only the implementation behind the layer.

Troubleshooting¶

Symptom	Likely cause	Fix
Platform Access matrix empty	Backend warming up	Refresh after 10 sec.
Save button doesn't activate	No change detected	Toggle a chip, ensure the yellow border appears.
Save returns 409	Concurrent edit by another admin	Refresh, re-apply, save.
Carol still sees masked columns in plain	Cache TTL	Wait 60 sec or click "Invalidate scope cache".
Audit log empty	Logs not seeded yet	Generate a few queries (chapter 04), then refresh.

What you just learned¶

Two RBAC dimensions : Platform (UI) and Data (rows / columns).
Scopes are server-side, append-only, audited.
Every denied access leaves a signed trail.

Next : 08 — Troubleshooting.
